Veil Nebula and NGC6940

Classification: Nebula / NGC6992 / NGC6992 / NGC6979
Constellation: Cygnus (CYG)
Object Location: Ra 20h 45m Dec +29° 47° (current)(Centered)
Size & Distance: Apx 3° Apx.1470 light years

Date & Location: 06-15/16-2012 Home
Exposure: HaOlllRGB, Ha=R-Olll=G&B, 16 ea.@ 15min. RGB= 10ea. @ 10min. All (bin 1x1)
Optics: Nikon 180ed lens open to f/5.6
Mount: Astro-Physics 900 GTO / ATS 10x36 pier
Camera: SBIG-STL6303E @-20c Guided by TV60 / SBIG-RGH
Filters: Astrodon 5nm Ha G2 RGB
Software: MaxImDL 4.56, Photoshop CS5

Notes: Sky conditions: Good seeing, Light wind, Temp low 40’s
Image Field of view is apx. 5° x 8°.
This image was an Astronomy Magazine Picture Of The Day. April, 2015
_____________________________________________________________

The Cygnus Loop is a large supernova remnant (SNR) in the constellation Cygnus, an emission nebula measuring nearly 3° across. Some arcs of the loop, known collectively as the Veil Nebula. The three main components of the Cygnus Loop consists of,
The Western Veil, NGC6960, C34.
The Eastern Veil, NGC6992, C33.
Pickering’s Triangle.
Open Cluster NGC6940 is to the lower right.
.
.
