M76 / Little Dumbbell

Classification: Planetary Nebula M76 / NGC650/651 / H193-1
Constellation: Perseus (PER)
Object Location: Ra 01h 43m 17s Dec +51° 39’00° (current)
Size & Distance: 3.1 x 3.1 Apx 2500 light years.

Date & Location: 09-09-2007 Palomar Mountain, CA.
Exposure: LRGB L= 7 @ 10 min. (bin 1x1) RGB= 4 ea. @ 5 min (bin 2x2)
Optics: Telescope Engineering Company APO140ED @ f/7 F/L 940mm.
Mount: Astro-Physics 900 GTO / ATS 10x36 pier.
Camera: Starlight-Xpress SXV-H9 w/ SXV guider head and 2045.
Filters: Astrodon G1 LRGB
Software: MaxImDL 4.56, Photoshop CS

Notes: Sky conditions: Average seeing, Light wind, Temp mid 60’s
Image Field of view is 23 x 31 arcmin.

The Little Dumbbell Nebula, also known as M76, NGC 650/651, the Barbell Nebula, or the Cork Nebula, is a planetary nebula in the constellation Perseus. It was discovered by Pierre Méchain in 1780 and included in Charles Messier's catalog of comet-like objects as number 76.

The Little Dumbbell Nebula derives its common name from its resemblance to the Dumbbell Nebula (M27) in Vulpecula. It was originally thought to consist of two separate emission nebulae and was thus given two catalog numbers in the NGC 650 and 651. Some consider this object to be one of the faintest and hardest to see objects in Messier's list.
